Belimo
Belimo - Stainless steel globe valve, 2-way, DN 15, Internal thread - H2..S Series
- Regular price
- $322.70
Secure Payment & Return Policies
Secure Payment & Return Policies
We use highly secure payment platforms, including Shop, Shopify Payments, Paypal, and Google Pay, to ensure your peace of mind. Here's what you can count on:
-
Secure Transactions: Our partners are industry leaders in payment security, using cutting-edge encryption to protect your data.
-
Fraud Protection: Rigorous fraud detection measures are in place to safeguard your transactions.
-
Flexible Payment Options: Choose from various trusted payment methods, including credit cards and digital wallets like Google Pay and Paypal.
-
Buyer Protection: Benefit from the buyer protection policies of our partners, ensuring refunds and dispute resolution.
-
Satisfaction Guarantee: We're confident in our products, and our customer support team is here to assist you if any issues arise.
- Return Policies: Please visit our policies to safely return any products that doesn't match your expectations.
Please feel free to contact us through our contact channels, our online chat there is always a team member online to help you out! If you prefer to call, our number is 0 401 690 551.
FAQs - Frequently Asked Questions
FAQs - Frequently Asked Questions
- Regular price
- $322.70
Business Credit Account Application
(Click here to see full screen)
Apply for a Business Credit Account with Tecnologia Shop, our team will review your application and contact you in 24h.
Upon approval, you will receive credit to spend on our store shown directly in your checkout along with all information needed.
Description: Stainless steel globe valve, 2-way, Internal thread.
- Suitable for open and closed cold and warm water systems.
- Designed for modulating control of air-handling and heating systems on the water side.
Type Overview:
- H215S-G: DN 15, Rp 1/2, kvs 1.6 m³/h, Stroke 10 mm, PN 25, n(gl) 3, Sv min. 100
- H215S-J: DN 15, Rp 1/2, kvs 4.0 m³/h, Stroke 10 mm, PN 25, n(gl) 3, Sv min. 100
- H220S-K: DN 20, Rp 3/4, kvs 6.3 m³/h, Stroke 10 mm, PN 25, n(gl) 3, Sv min. 100
- H225S-L: DN 25, Rp 1, kvs 10 m³/h, Stroke 15 mm, PN 25, n(gl) 3, Sv min. 100
- H232S-M: DN 32, Rp 1 1/4, kvs 16 m³/h, Stroke 20 mm, PN 25, n(gl) 3, Sv min. 100
- H240S-N: DN 40, Rp 1 1/2, kvs 25 m³/h, Stroke 20 mm, PN 25, n(gl) 3, Sv min. 100
- H250S-P: DN 50, Rp 2, kvs 40 m³/h, Stroke 20 mm, PN 25, n(gl) 3, Sv min. 100
Functional Data:
- Fluid: Cold, warm, and hot water, water with glycol up to max. 50% vol.
- Fluid temperature: 0...130°C [32...266°F]
- Flow characteristic: Equal percentage (VDI/VDE 2173) n(gl) = 3, optimized in the opening range
- Leakage rate: Max. 0.01% of the kvs value
- Closing point: Top (▲)
- Pipe connection: Internal thread according to ISO 7-1
- Installation position: Upright to horizontal (in relation to the stem)
- Servicing: Maintenance-free
Materials:
- Valve body: Stainless steel AISI 304
- Closing element: Stainless steel AISI 304
- Spindle: Stainless steel AISI 304
- Spindle seal: PTFE+FFKM
- Seat: Stainless steel AISI 304
Part Numbers:
H215S-G: DN 15 - RP 1/2 - m/h 1.6 - Stroke 10mm
H215S-J: DN 15 - RP 1/2 - m/h 4.0 - Stroke 10mm
H220S-K: DN 20 - RP 3/4 - m/h 6.3 - Stroke 10mm
H225S-L: DN 25 - RP 1 - m/h 10 - Stroke 15mm
H232S-M: DN 32 - RP 1 1/4 - m/h 16 - Stroke 20mm
H240S-N: DN 40 - RP 1 1/2 - m/h 25 - Stroke 20mm
H250S-P: DN 50 - RP 2 - m/h 40 - Stroke 20mm
Need help to order a specific Part-Number? Contact Us!
