AIR VELOCITY AND TEMPERATURE TRANSMITTER IVL 10

Description: The IVL 10 air velocity and temperature transmitter is specifically designed for HVAC applications. It provides output signals corresponding to the air flow velocity and temperature within the ventilation duct. The transmitter is intended to be mounted inside the duct in an area where the air flow is as laminar as possible. Both output signals can be individually selected to be either 4…20 mA or 0…10 V.

The N model features a display with a resolution of 0.1 m/s for velocity and 0.1 °C for temperature. The display can be added even after commissioning. The measurement values scroll on the display, but the desired value can be locked for continuous viewing by removing the jumper on the back of the display board. Additionally, all models are available with stem lengths of 100 mm and 400 mm.

Technical Data:

  • Supply:

    • 24 Vac (22…28 V), < 1.5 VA
    • 24 Vdc (23…28 V), < 1.5 W

  • Ranges:

    • Velocity: 0…10 m/s
    • Temperature: 0…50 °C

  • Outputs:

    • 0…10 V, < 2 mA
    • 4…20 mA, < 600 Ω

  • Accuracy:

    • Velocity: ±0.5 m/s ±7% from reading (at 25°C)
    • Temperature: ±0.5 °C (25°C, > 0.5 m/s)

  • Operating Temperature: 0…50°C

  • Mounting: Adjustable flange

  • Stem: 10 x 200 mm

  • Housing: IP54 (transmitter), probe or cable gland downwards

  • Materials: PBT, PC, PA, and stainless steel

Part Numbers:
IVL 10 - Air Velocity Transmitter 0-10M/S
IVL 10-400 - Air Velocity Transmitter 400Mm
IVL 10-N - Air Velocity Transm. & Display
IVL 10-100 - Air Velocity Transm. 0-10M/S 100Mm
IVL 10-400-N - Air Velocity Transmitter 400Mm
IVL 10-100-N - Air Velocity Transm.& Display 100Mm
IVL 02 - Air Velocity Transm. 0...2M/S
IVL 02-400 - Air Velocity Transmitter 400Mm
IVL 02-N - Air Velocity Transm. & Display
IVL 02-100-N - Air Velocity Transm.100Mm & Display
IVL 02-100 - Air Velocity Transm. 0...2M/S
IVLJ 02 - Air Velocity Transm. 0-2M/S
IVLJ 02-100 - Air Velocity Transm. Cable 0-2M/S
IVL 20 - Air Velocity Transmitter 0-20 M/S
IVL 20-400 - Air Velocity Transmitter 400Mm
IVL 20-N - Air Velocity Transm. & Display
IVL 20-400-N - Air Velocity Transmitter 400Mm
IVLJ 10 - Air Velocity Transm. Cable 0-10M/S
IVLJ 10-N - Air Velocity Transm. Cable 0-10M/S
IVLJ 20 - Air Velocity Transm. Cable 0-20M/S
IVLJ 20-N - Air Velocity Transm. Cable 0-20M/S


Need help to order a specific Part-Number? Contact Us!
