Series RHP Humidity/Temperature Transmitters

Description: The Series RHP Humidity/Temperature Transmitters are versatile devices designed to provide accurate and reliable measurements of both humidity and temperature. Featuring models with 2%, 3%, or 5% accuracy, these transmitters are suitable for various project requirements. With integral temperature sensors, the need for additional devices is reduced, simplifying installation and maintenance. An optional radiation shield protects the sensor from radiant heating effects, ensuring accurate readings even in direct sunlight. Applications include air economizers and outdoor temperature and relative humidity reference for building systems.

Specifications:

  • Relative Humidity Range: 0 to 100% RH.
  • Temperature Range: -40 to 140°F (-40 to 60°C).
  • Accuracy, RH: RHP-2XXX ±2% 10-90% RH @ 25°C; RHP-3XXX ±3% 20-80% RH @ 25°C; RHP-5XXX ±5% 20-80% RH @ 25°C.
  • Accuracy, Thermistor Temp Sensor: ±0.2°C @ 25°C (±0.36°F @ 77°F).
  • Accuracy, RTD Temp Sensor: DIN Class B; ±0.3°C @ 0°C (±0.54°F @ 32°F).
  • Accuracy, Solid State Band Gap: ±0.9°F @ 77°F (±0.3°C @ 25°C).
  • Hysteresis: ±1%.
  • Repeatability: ±0.1% typical.
  • Temperature Limits: -40 to 140°F (-40 to 60°C).
  • Storage Temperature: -40 to 176°F (-40 to 80°C).
  • Compensated Temperature Range: -4 to 140°F (-20 to 60°C).
  • 4-20 mA Loop Powered Models: Power requirements: 10-35 VDC; Output signal: 4-20 mA.
  • 0-5/10 V Output Models: Power requirements: 15-35 VDC or 15-29 VAC; Output signal: 0-10 V @ 5 mA max.
  • Response Time: 15 s.
  • Electrical Connections: Removable screw terminal block.
  • Conduit Connection: Duct mount: 1/2˝ NPS; OSA: PG11 or PG16 (1/2˝ conduit) knockouts.
  • Drift: < 1% RH/year.
  • RH Sensor: Capacitance polymer.
  • Temperature Sensor Types: 1, 2, 3: Solid state band gap; Curves A, B, C: Thermistor; Curves D, E: Platinum RTD DIN 385.
  • Enclosure: Duct mount: PBT; OSA: Polycarbonate.
  • Enclosure Rating: Duct mount: NEMA 4X (IP66) for housing only; OSA: NEMA 4X (IP66).
  • Display: Duct mount only, optional 2-line alpha numeric, 8 characters/line.
  • Display Resolution: RH: 0.1%; 0.1°F (0.1°C).
  • Weight: Duct mount: .616 lb (.3 kg); OSA: 1 lb (.45 kg).
  • Agency Approvals: CE.

The Series RHP Humidity/Temperature Transmitters offer precise and reliable measurements, making them ideal for applications such as air economizers and outdoor temperature and humidity monitoring in building systems. With various accuracy options and integral temperature sensors, these transmitters provide flexibility and ease of use in diverse environments.

Part Numbers:

RHP-3R10 Outside Air Humidity Sensor Radiation Shield Humidity 3% 4-20mA no Temp
RHP-3R11 Outside Air Humidity Temp Sensor Radiation Shield Humidity 3% 4-20mA Temp - 4-20mA
RHP-3R1A Outside Air Humidity Temp Sensor Radiation Shield Humidity 3% 4-20mA Temp - 10 kOhm Type III
RHP-3R1B Outside Air Humidity Temp Sensor Radiation Shield Humidity 3% 4-20mA Temp - 10 kOhm Type II
RHP-3R1C Outside Air Humidity Temp Sensor Radiation Shield Humidity 3% 4-20mA Temp - 3 kOhm
RHP-3R1D Outside Air Humidity Temp Sensor Radiation ShieldHumidity 3% 4-20mA Temp - 100 Ohm RTD
RHP-3R1E Outside Air Humidity Temp Sensor Radiation Shield Humidity 3% 4-20mA Temp - 1 kOhm RTD
RHP-3R1F Outside Air Humidity Temp Sensor Radiation Shield Humidity 3% 4-20mA Temp - 20 kOhm
RHP-3O10 Outside Air Humidity Sensor Humidity 3% 4-20mA no Temp
RHP-3O11 Outside Air Humidity Temp Sensor Humidity 3% 4-20mA Temp - 4-20mA
RHP-3O1A Outside Air Humidity Temp Sensor Humidity 3% 4-20mA Temp - 10 kOhm Type III
RHP-3O1B Outside Air Humidity Temp Sensor Humidity 3% 4-20mA Temp - 10 kOhm Type II
RHP-3O1C Outside Air Humidity Temp Sensor Humidity 3% 4-20mA Temp - 3 kOhm
RHP-3O1D Outside Air Humidity Temp Sensor Humidity 3% 4-20mA Temp - 100 Ohm RTD
RHP-3O1E Outside Air Humidity Temp Sensor Humidity 3% 4-20mA Temp - 1 kOhm RTD
RHP-3O1F Outside Air Humidity Temp Sensor Humidity 3% 4-20mA Temp - 20 kOhm
RHP-3S10 Outside Air Humidity Sensor Sintered Filter Humidity 3% 4-20mA no Temp
RHP-3S11 Outside Air Humidity Temp Sensor Sintered Filter Humidity 3% 4-20mA Temp - 4-20mA
RHP-3S1A Outside Air Humidity Temp Sensor Sintered Filter Humidity 3% 4-20mA Temp - 10 kOhm Type III
RHP-3S1B Outside Air Humidity Temp Sensor Sintered Filter Humidity 3% 4-20mA Temp - 10 kOhm Type II
RHP-3S1C Outside Air Humidity Temp Sensor Sintered Filter Humidity 3% 4-20mA Temp - 3 kOhm
RHP-3S1D Outside Air Humidity Temp Sensor Sintered FilterHumidity 3% 4-20mA Temp - 100 Ohm RTD
RHP-3S1E Outside Air Humidity Temp Sensor Sintered Filter Humidity 3% 4-20mA Temp - 1 kOhm RTD
RHP-3S1F Outside Air Humidity Temp Sensor Sintered Filter Humidity 3% 4-20mA Temp - 20 kOhm
RHP-3R10 Outside Air Humidity Sensor Radiation Shield Humidity 3% 4-20mA no Temp
RHP-3R11 Outside Air Humidity Temp Sensor Radiation Shield Humidity 3% 4-20mA Temp - 4-20mA
RHP-3R1A Outside Air Humidity Temp Sensor Radiation Shield Humidity 3% 4-20mA Temp - 10 kOhm Type III
RHP-3R1B Outside Air Humidity Temp Sensor Radiation Shield Humidity 3% 4-20mA Temp - 10 kOhm Type II
RHP-3R1C Outside Air Humidity Temp Sensor Radiation Shield Humidity 3% 4-20mA Temp - 3 kOhm
RHP-3R1D Outside Air Humidity Temp Sensor Radiation ShieldHumidity 3% 4-20mA Temp - 100 Ohm RTD
RHP-3R1E Outside Air Humidity Temp Sensor Radiation Shield Humidity 3% 4-20mA Temp - 1 kOhm RTD
RHP-3R1F Outside Air Humidity Temp Sensor Radiation Shield Humidity 3% 4-20mA Temp - 20 kOhm

Please refer to the datasheet to check models capabilities.
